WLA-12SDP single 18-inch source line array ultra-low speaker

Share to:

WLA-12SDP single 18-inch source line array ultra-low speaker

The WLA series is a two -point frequency line. After long -term exploration and market demand, the GA R & D team has developed a high -end and high -end venue such as the banquet hall of the conference hall. The perfect combination of phase technology and waveguide technology ensures the uniformity and direction of sound field. The unique horn design enables the speakers to perfectly superimposed and combines to ensure the sound quality and extremely low distortion rate of the WLA series, and it is more convenient and flexible.

Application scenario:

Mobilization
bar
stadium
Concert
hall

Availability:



Inquire

Model:
Wla-12sdp

Product Description

System type:	Single 18 -inch source line array ultra -balcony
Module input sensitivity:	0.775V
Module power interface:	Power CON
Module output power:	1200w/8Ω
Frequency range:	28Hz-400Hz ± 3dB
Drive unit:	LF: 1*18 "(100mm)
Sensitivity:	100db SPL 1W/1M
Extreme sound pressure level:	136DB
The rated impedance:	8Ω
Input power (continuous/music/peak):	650W/1300W/2600W
Enter the interface:	2xneutrik® NL4MP
size	780632760mm
net weight:	65 kg/only
